Cast-resin busbar for harsh environments
E-Line CR
E-Line CR cast-resin busbar trunking systems provide power transfer and distribution between 630 A and 6300 A. Explosion-protected and compatible with E-Line KX busbar modules, the CR range is rated IP68. The DURACOMP composite material, with high mechanical and working strength, made of specially selected pure silicon minerals and epoxy resin, protects the conductors from external impact and makes the busbar waterproof and suitable for burial.
Technical Features
Current range
630 A to 6300 A current range
Rated performance taken from the original product datasheet.
Ingress protection
IP68 and IP69K protection class
Protection and service continuity declared by the manufacturer.
Conductors
Fully tinned aluminium or copper conductors
Conductor configuration and materials available for the range.
Configuration
Configurable with 4 / 4½ / 5 / 6 conductors
Key construction element or configuration of the busbar solution.
Features
- 630 A to 6300 A current range
- IP68 and IP69K protection class
- Fully tinned aluminium or copper conductors
- Configurable with 4 / 4½ / 5 / 6 conductors
- Enclosure made of a composite material of pure silicon minerals and epoxy resin
- Compatible with E-Line KX modules
- Dedicated earth conductor option
- Corrosion resistant
- Resistant to chemicals
- Pest resistant
- Suitable for tropical environments
- High mechanical strength
