Aluminium cable ladder
E-LINE KCA AL
The E-Line KCA AL aluminium alloy cable ladder is designed to meet the need for high performance in every type of heavy-duty application.
Technical Features
Dimensions and thicknesses
NEMA 20C for the ladder with 150 mm height
Dimensional configurations and main variants declared by the manufacturer.
Material and finish
Made of high-quality 6063-T6 aluminium alloy, marine-grade material
Main construction materials or finishes of the range.
Tests and certifications
IEC 61537 tested and certified by DEKRA
References to standards, tests or certifications in the original datasheet.
Configuration
Standard length 3 and 6 m
Distinctive construction element or installation detail of the solution.
Features
- IEC 61537 tested and certified by DEKRA
- NEMA VE-1 tested and certified by DEKRA
- NEMA 20C for the ladder with 150 mm height
- NEMA 12C for the ladder with 100 mm height
- High resistance to chemical corrosion and extremely durable
- Made of high-quality 6063-T6 aluminium alloy, marine-grade material
- Tested according to DIN 4102-12 at 1000 °C for 90 minutes and at -70 °C
- Superior cable-carrying capacity thanks to its heavy-duty structural design
- High load capacity thanks to the specially designed side rails
- Tested in difficult conditions
- Standard length 3 and 6 m
- High production capacity (6 metres per minute)
Applications
Heavy-duty applicationsCorrosive environmentsLightweight, high-strength installationsMarine or industrial applications
